Haas VF4-APC CNC Vertical Machining Center

Make Haas

Model: VF4 APC

Control: Haas

S/N: 22470

Year: 2000

Specifications:

Table size: 50” x 18”

X axis travel: 50”

Y axis travel: 20”

Z axis travel: 25”

Main spindle: 10,000 RPM

Main motor: 20 HP, 480V

Tool changer: 25 station

Spindle taper: CAT40

Spindle nose to table: 4-29”

Maximum table load: 3,500 LBS

Horse Power: 20HP

Machine weight: 13,500 LBS

Equipped with: 2 speed gearbox, Brushless servos, Rigid tapping, Chip auger, USB port, 1 MB extended memory, Thru spindle coolant, High pressure unit, Programmable coolant, Coolant Tank, Pallet Shuttle
